ATEN 8” Professional Smart Automation Touch Panel Hub (VK320 / TPA08-M3A)
Take supreme command of your automated environment with the ATEN VK320 Smart Touch Panel (TPA08-M3A Edition). Featuring an elegant 8-inch capacitive multi-touch IPS-LCD screen with a modern narrow bezel, this executive-tier console serves as the definitive central command center for luxury villas, high-end hotel suites, smart boardrooms, and digital podiums. Operating over a secure, single-cable Power over Ethernet (PoE) connection, it brings together native ATEN system control with advanced IoT infrastructure—housing an integrated Zigbee/BLE gateway, built-in Amazon Alexa, an infrared (IR) blaster, a 2-gang relay switch, and dual-channel wired ceiling speaker amplification in one striking, wall-mounted interface.
Key Features
-
Multi-Protocol Local Edge Gateway: Equipped with built-in Zigbee and Bluetooth LE (SigMesh) gateways alongside an integrated IR blaster. Control everything from smart blinds and lighting grids to older legacy media players directly from the wall panel with zero extra external hubs.
-
Built-in Alexa & Background Music Engine: Features native Amazon Alexa Voice Service integration for instant, hands-free smart home commands. Coupled with a premium background music architecture, it drives high-fidelity multi-room audio playback effortlessly.
-
Integrated Hardware Relays & Audio Output: Engineered with a specialized 2-way wired ceiling speaker output and an onboard 2-gang relay switch matrix. This allows you to directly wire physical light loads and premium audio speakers straight to the station without extra sub-controllers.
-
Single-Cable PoE Stability: Supports advanced Power over Ethernet (PoE). Run both high-speed data streams and rock-solid electrical power through a single Ethernet cable, completely avoiding unstable Wi-Fi drops in enterprise or luxury residential layouts.
-
Fluid AppSwitcher UI & Ecosystem Sync: Natively loaded with the ATEN Control System app, fully supporting AppSwitcher to cycle seamlessly between different smart apps. It integrates natively with ATEN Unizon and ATEN Room Booking systems to display live room utilization and operation timelines.
-
Flexible Equilateral Orientation: The uniform, symmetry-driven structural casing lets administrators mount the screen in either a wide horizontal landscape or a sleek vertical portrait layout to perfectly complement your interior architecture.
Technical Specifications
| Feature | Specification |
| Brand & Model | ATEN VK320 / TPA08-M3A Smart Hybrid Edition |
| Display Panel | 8-Inch Capacitive Multi-Touch IPS-LCD (Narrow Bezel) |
| Wireless IoT Gateway | Zigbee Mesh + Bluetooth LE Mesh + Built-in IR Blaster |
| Voice / Audio Engine | Native Built-in Amazon Alexa + Background Music Processing |
| Hardware Terminals | 2-Way Wired Ceiling Speaker Ports + Integrated 2-Gang Relay Switch |
| Power Infrastructure | Power over Ethernet (PoE) / Wired Network Interface |
| Video Stream Support | Real-Time RTSP, ONVIF Protocol, and ATEN VE89 Series Video Preview |
| Security Controls | Administrator Central Multi-Room Management & Password Profiles |
| Aesthetics & Indicators | Built-in Side Power LED Status Bars (For dark-room visibility) |
Mounting & Installation Versatility
The VK320 features an architectural-grade in-wall design that mounts completely flush into standard 86-type junction boxes. Its adaptable mounting plate is fully compatible with standard decorator-style, 1-gang junction boxes across US, EU, and MK regional specifications. For premium desktop placement on boardroom tables, reception counters, or executive desks, the panel integrates flawlessly with the optional VK101 and VK102 Tabletop Kits.
Why Choose the ATEN VK320 Smart Hub?
The VK320 (TPA08-M3A variant) transforms your property from a collection of scattered smart gadgets into a unified, high-tech sanctuary. By consolidating a professional PoE touchscreen controller, an industrial Zigbee gateway, an Alexa smart speaker, physical light relays, and a background audio amplifier into a single 8-inch glass interface, it eliminates cluttered walls and app fatigue. It is the ultimate premium asset for modern system integrators, luxury homeowners, and commercial space planners who demand a futuristic aesthetic backed by bulletproof, hardwired reliability.
